Features:
The industry's most complete water purification solution for highly regulated applications.
When your application requires the ultimate in water purity, Smart Plus provides the perfect solution.
Consistently delivering water purity of 18.2MΩ.cm and underpinned by the advanced technologies, the Smart Plus enables you to focus on attaining accurate results while ensuring an uninterrupted work flow.
Typical scientific applications:
ICP-MS(Inductively Coupled Plasma Mass Spectrometry)
Molecular biology techniques
Ultra trace analysis
Electrochemistry
Electrophoresis
GFAAS(Graphite Furnace Atomic Absorption Spectrophotometry)
HPLC
IC(Ion Chromatography)
ICP-AES(Inductively Coupled Plasma Atomic
Emission Spectrometry)
Mammalian and bacterial cell culture
Molecular biology
Plant tissue culture
Qualitative analysis
Configurations:
| INOSP-N Systems | INOSP-N | INOSP-NT | INOSP-NE | INOSP-NET |
| Pretreatment Module | ✓ | ✓ | ✓ | ✓ |
| High Pressure Pump | ✓ | ✓ | ✓ | ✓ |
| Reverse Osmosis | ✓ | ✓ | ✓ | ✓ |
| Dual Wavelength UV-lamp | ✓ | ✓ | ✓ | ✓ |
| Ultra-Purification Cartridge | ✓ | ✓ | ✓ | ✓ |
| Ultra-Filtration Cartridge | ✓ | ✓ | ✓ | ✓ |
| EDI Module | x | x | ✓ | ✓ |
| Point-of-use Filter | ✓ | ✓ | ✓ | ✓ |
| Storage Tank 30L | ✓ | ✓ | ✓ | ✓ |
| Air Filter Net For Tank | ✓ | ✓ | ✓ | ✓ |
| UV-lamp Sterilizer For Water Tank | ✓ | ✓ | ✓ | ✓ |
| Remote Water Dispenser With Color Display | ✓ | ✓ | ✓ | ✓ |
| TOC Monitoring Module | x | ✓ | x | ✓ |
Technical Specification:
| Model | INOSP-N | INOSP-NT | INOSP-NE | INOSP-NET |
| Feed Water Requirement | ||||
| Source | Tap water | |||
| Conductivity | <2000us/cm | |||
| Hardness | <450ppm as CaCO3 | |||
| Pressure | 0.05～0.5MPa(7-72psi) | |||
| Temperature | 5～40˚C | |||
| Purification Water(Class III) | ||||
| Ionic Rejection | >95% | |||
| Bacteria Rejection | >99% | |||
| Conductivity | 1～20us/cm | |||
| Productivity Rate | 30L/h | |||
| High Quality Purification Water(Class II) | ||||
| Resistivity At 25C | / | 10MΩ.cm | ||
| TOC | / | <30ppb | ||
| Dissolved Organic | / | <0.1ppm | ||
| Productivity Rate | / | 15L/h | ||
| Ultrapurification Water(Class I) | ||||
| Resistivity At 25˚C | 18.2MΩ.cm | |||
| Conductivity At 2˚C | 0.055us/cm | |||
| TOC Level | 1～5ppb | |||
| Endotoxin(Pyrogens) | <0.001EU/ml | |||
| Particulate(≥0.02um) | <1pc/ml | |||
| Bacteria | <0.1 cfu/ml | |||
| Rnase/Dnase | Free | |||
| Manual Dispense Flow Rate | 1.5～2.0L/min | |||
| Automatic Dispense Volume | 100～60000ml | |||
| Electrical Requirements | ||||
| Electrical Voltage | 110V/220V±10% | |||
| Electrical Frequency | 50HZ/60HZ | |||
| Packing Information(Net Weight) | ||||
| Main Units | 34kg | 35kg | ||
| Water Tank(30L) | 15kg | |||
| External Dimensions(WxDxH) | ||||
| Main Units | 315x525x570mm | |||
| Water Tank(30L) | 380x380x595mm | |||
| Shipping Weight | ||||
| Main Units | 37kg | 39kg | 37kg | |
| Water Tank(30L) | 15kg | |||
| Shipping Dimensions(WxDxH) | ||||
| Main Units | 525x610x770mm | |||
| Water Tank(30L) | 520x440x615mm |
|||
