Features:
Incorporating with electrodeionization module, INOS-ROE can continuously supply type II purified water.
Push-to-sterilize
Just a simple key press to sterilize reverse osmosis, recirculation pumpline and water tank, ensuring water quality
Touch screen control
8.0 inches colored display for multi-parameters
Intelligent control with man-machine interaction
Filter life indicator with alarm function in time
Internal 60L water tank
Water tank is integrated into the main structure to save your valuable laboratory space.
The water reservoir is made through cylindrical mold and blow molding process to avoid the generation of velum.
PE material ensure low extractives.
Optional UV lamp and vented filter mantain consitent purity of stored water
EDI module
Resins are continuously regenerated by the electrical current and are never exhausted.
Low operating cost, low engergy consuption and low maintenance.
Backup
Duplex operation (i.e. two linked Pureforce ROB units) to provide an even greater operational contingency that avoids a single point of failure
Additional features
Strengthened purification cartridges- loaded with PP cotton, active carbon, softten resin meet large volume reuirement, optimizing the following purification efficiency
Unique reverse osmosis- flow restriction design with automated forward and backward rinse increases lifespan of the module by 50%
Patented resistivity meter- compact type meters with low cell constant (0.01cm-1) and automatic temperature compensation make the value meaningful
Simple modular design- standard modular consumables and accessories facilitate daily operation and maintenance.
Technical Specifications:
Model | INOS-ROE-70 | INOS-ROE-100 | |
Productivity Rate | 70L/h | 100L/h | |
Feed Water Requirement | |||
Source | Tap water | ||
Conductivity | <2000us/cm | ||
Hardness | <450ppm as CaCO3 | ||
Pressure | 0.1~0.5MPa | ||
Temperature | 5~40˚C | ||
High Quality Purification Water(Class II) | |||
Resistivity At 25˚C | 10MΩ.cm | ||
TOC | <30ppb | ||
Dissolved Organic | <0.1ppm | ||
Particulate(≥0.02um) | <1pc/ml | ||
Bacteria | <1cfu/ml | ||
Flow Rate | 3.0~4.0L/min | ||
Electrical Requirements | |||
Electrical Voltage | 110V/220V±10% | ||
Electrical Frequency | 50Hz/60Hz | ||
Packing Information(Net Weight) | |||
Main Units | 120kg | ||
External Dimensions(WxDxH) | |||
Main Units | 650x715x1650mm | ||
Shipping Weight | |||
Main Units | 150kg | ||
Shipping Dimensions(WxDxH) | |||
Main Units | 735x780x1790 |
Configurations:
Model | INOS-ROE-70 | INOS-ROE-100 |
Description | ROE Water Purification System, 70 Litres | ROE Water Purification System, 100 Litres |
Power Supply | Standard configuration - 220V/50Hz | |
Available upon special request - 220V/60Hz & 110V/60Hz | ||
Features | 70L/hr output (pure water) | 100L/hr output (pure water) |
Inlet water requirement: tap water | ||
Output water Resistance: 10~15ΜΩ.cm | ||
Particles (≤0.22μm): ≤1/ml | ||
Bacteria: ≤1cfu/ | ||
TOC: ≤30ppb | ||
Bacteria rejection rate:>99% | ||
Standard Configurations | Main Unit | |
Pre-treatment module (SP101L) | ||
High pressure pump (SP610) | ||
RO module (CE-SP207) ×2 | RO module (CE-SP207) ×3 | |
EDI module (SPC-70) | EDI module (SPC-100) | |
Purification cartridge (SP301L) | ||
Single wavelength UV-lamp 254nm (SPMWUV-1) | ||
Micro-filtration cartridge (SP502) | ||
ST-60S water tank 60 litres, including pump and 5-level float sensors (SP410) | ||
Air filter net for tank (SP412) | ||
Supply pump (SP610B) | ||
Optional Accessories | Please see Appendix |
