Features ;
InoPurauto-Mini Microplate reader is designed with compact shape and modern operating software, aiming to save space, facilitate operation and offer a new user experience.
> Small and simple designIt is approximately the size of two microplates that can be measured on a modular bench, anaerobic chamber, or incubator.
> Long-lasting LED light sourceIt does not require maintenance and saves energy with low power consumption.
> Independent removable light source and filter module450/630nm and 405/492nm. External can be customized with any wavelength.
> Reliable data guaranteeIt features a reference optical path system to ensure stable and reliable detection data.
> Multiple detection modesIt can detect single wavelength, double wavelength, kinetics etc.
Technical Specifications ;
|
Model |
InoElisaR-Mini |
|
Detection Type |
Endpoint, kinetic |
|
Plate Type |
96-well |
|
Light Source |
LED x2 |
|
Detector |
PD x9 |
|
Wavelengt Accuracy |
≤±2nm |
|
Wavelength Range |
340 - 750nm |
|
Filter |
450/630nm, 405/492nm |
|
Measure Range |
0-4 OD |
|
Resolution |
0.001 OD |
|
Linear |
R2 ≥ 0.995 @ [0.0 - 3.0 OD] |
|
Accuracy |
≤±(0.5%+0.01 OD) @[0.0-2.0 OD) ≤±(1.0%+0.01 OD) @ [2.0-3.0 OD) |
|
Repeatability |
[0,3) CV ≤0.5% |
|
Stability |
≤0.005 Abs [0.0, 2.0 Abs) ; ≤0.3% [2.0, 3.0 Abs) |
|
Measure Speed |
Single wavelength <15s/96-well, Dual wavelength <28s/96-well |
|
Software / Language |
APP / English |
|
Compatibility |
Support PC Software, Win7/Win10 64bit |
|
Transmission |
Bluetooth, USB cable |
|
Instrument Port |
1 Type-C interface, 1 USB A-port |
|
Power Input |
USB 5V 3A |
|
Dimension (WxDxH) |
138x221x89mm |
|
Weight |
2.5 Kg |
