Features;
1. Throughput: 60T/H.
2. 14inch Touch Screen
3. Tri-angle laser scatter + flow cytometry method + impedance method for RBC and PLT counting.
4. 3D holographic scatergram displays the accurate 5 part differentiation of WBC.
5. Large storage capacity:100,000 results (including histogram, scattergram, patient information)
Technical Specifications;
|
Model |
IHA-T50 |
|
Throughput |
60 Tests/hour |
|
Assay Items |
5 parts, 29 parameters, 3 histograms |
|
Principle |
Tri-angle laser scatter, Flow cytometry method, 3D scattergram analysis, Impedance method for RBC and PLT counting, Cyanide free reagent for HGB test |
|
Test Mode |
CBC mode, CBC+DIFF mode Venous whole blood, Capillary whole blood and Prediluted |
|
Parameters |
WBC, RBC, HGB, HCT, MCV, MCH, MCHC, RDW-SD, RDW-CV, PLT, MPV, PCT,PDW, P-LCR, P-LCC, NEU%, LYM%, MON%, EOS%, BAS%, NEU%, LYM#, MON#, EOS#, BAS#, 4 Research paramteter: ALY%, ALY#, IG%, IG# |
|
Sample Volume |
CBC+DIFF mode: ≤20µl CBC mode: ≤10µl |
|
Storage |
100,000 results including histogram, scattergram and patient information |
|
Interface |
4 USD Port, 1 LAN Port, Bi-direction LIS, Suppot HL7 protocol, Internal RFID reader |
|
Power Supply |
AC220V ±10% 50/60Hz, 110V ±10% 60Hz, 400VA |
|
Package Size (WxDxH) |
670x590x790mm |
|
Reagent Package Size (WxDxH) |
320x320x290mm |
|
Gross Weight |
53 Kg |
|
Reagent Gross Weight |
22 Kg |
