Features:
Our newly designed touch screen refrigerated centrifuge devices are generally used in blood banks, laboratories and hospitals for processes such as plasma, platelet and erythrocyte separation from whole blood.
It has high torque, micro process or adjustment and maintenance-free, dust-free brushless motor.
The flexible shaft system with direct drive and rotor can tolerate imbalance of up to 10 grams, thusensuring smooth operation, low noise and small vibration.
It has imported compressor and precise temperature control, which does not create environmental pollution, can easily beconverted to cold and hot, fluorine-freedouble-cyclecooled.
It has up to 10 different process recording memories and adjustable acceleration in 9 different stages and deceleration function in 10 different stages.
Micro-computer control allows you to easily process all the parameters you need such as RPM/RCF, Time, Temperature and Acceleration-Deceleration via LCD touchscreen.
Electric automatic lock system, super speed and unbalance protection.
The centrifuge body is made of high qualitysteel, safe and reliable, and the top cover has an inspection window for calibration.
With the reliable locking system and sensors, the device does not start without closing the door and the door can not be opened until the device is completely stopped. In the event of a power failure, the door can be opened with the manual key located on the side of the device.
The device is equipped with sensors and alarm systems to alertthe user to any malfunction or misuse.
Also the features at the display and inside of the menu at the panel can provide you;
* Set the "SleepTime" for the device,
* Set the "Buzzer" coming at the end of process,
* Set the "Timer" according to temperature or RPM for operating time of the device,
* Set the "Defrost" for the solve or keep icing,
* Set the "Lid Mode" for the end of process, you can set the cover manually or automatically.
* Up to 10 memory capacity for different operations.
* Adjustable RPM/RCF, Time, Temperature and adjustable 9 different acceleration and 10 different deceleration functions via LCD touch screen.
Technical Specifications;
|
Model |
BRC-MICRO |
BRC-5180T |
BRC-5180UT |
BRC-5300T |
BRC-5300UT |
| Maximum Speed (RPM) | 16000 | 18500 | 21000 | 18500 | 21000 |
| Maximum RCF (xg) | 19041 | 23990 | 31910 | 23990 | 30910 |
| Maximum Capacity | 6x50ml | 4x180ml | 4x180ml | 4x300ml | 4x300ml |
| Temperature Range | -20°C - 40°C | ||||
| Temperature Accuracy | ±1°C | ||||
| Speed Accuracy | ±50rpm/min | ±20rpm/min | |||
| Timer Range | 0 - 99min | ||||
| Noise | ≤58dB (A) | ≤55dB (A) | ≤60dB (A) | ||
| Power Supply | AC220V 50Hz 5A | AC220V 50Hz 5A | AC220V 50Hz 7A | AC220V 50Hz 6A | AC220V 50Hz 7A |
| Dimension (mm)(WxDxH) | 490x500x270 | 570x600x455 | 570x600x340 | 640x665x400 | 660x665x375 |
| Package Dimensions (mm)(WxDxH) | 670x570x270 | 750x670x455 | 750x670x455 | 820x735x535 | 820x735x535 |
| Net/Gross Weight (kg) | 44/57 | 105/118 | 105/118 | 120/132 | 100/117 |
Rotor Types;
| Model Rotor Type |
BRC-MICRO | BRC-5180T | BRC-5180UT | BRC-5300T | BRC-5300UT | |
| Capacity | RPM RCF(xg) | RPM RCF(xg) | RPM RCF(xg) | RPM RCF(xg) | RPM RCF(xg) | |
| Angle (Fixed) Rotor |
40 x 0.2ml | 16000 19041 | 16000 19041 | 16000 19041 | 16000 19041 | 16000 19041 |
| 24 x 0.5ml | 16000 18481 | 16000 18481 | 16000 18481 | 16000 18481 | 16000 18481 | |
| 30 x 0.5ml | 13000 13906 | 13000 13906 | 13000 13906 | 13000 13906 | 13000 13906 | |
| 40 x 0.5ml | 13000 17218 | 14000 19960 | 15000 22920 | 14000 19960 | 15000 22920 | |
| 12 x 1.5/2.0ml | 16000 17948 | 18500 23990 | 21000 30910 | 18500 23990 | 21000 30910 | |
| 20 x 1.5/2.0ml | 14000 15585 | 14000 15585 | 14000 15585 | 14000 15585 | 14000 15585 | |
| 24 x 1.5/2.0ml | 14000 17956 | 15000 20600 | 16000 23440 | 15000 20600 | 16000 23440 | |
| 30 x 1.5ml | 13500 19340 | 14000 20800 | 13500 19340 | 14000 20800 | ||
| 30 X 2ml | 13500 19340 | 13500 19340 | 13500 19340 | |||
| 48 x 1.5ml | 11000 12840 | 13000 17930 | 11000 12840 | 13000 17930 | ||
| 10 x 5ml | 16000 17882 | 16000 17882 | 16000 17882 | 16000 17882 | 16000 17882 | |
| 16 x 5ml | 15000 19350 | 16000 22020 | 15000 19350 | 16000 22020 | ||
| 12 x 10ml | 13000 17030 | 15000 22680 | 13000 17030 | 15000 22680 | ||
| 16 x 10ml | 11000 13950 | 13000 19490 | 11000 13950 | 11000 13950 | ||
| 6 x 10/15ml | 13000 14196 | 14000 16460 | 16000 21500 | 14000 16460 | 16000 21500 | |
| 8 x 15ml | 11000 12730 | 11000 12730 | 11000 12730 | 13000 17790 | ||
| 8 x 15ml(Sharp) | 11000 12730 | 11000 12730 | 11000 12730 | |||
| 8 15ml(Conical) | 13000 17790 | 13000 17790 | 13000 17790 | |||
| 12 x 15ml | 9000 9590 | 11000 14330 | 9000 9590 | 11000 14330 | ||
| 4 x 8 PCR | 14000 12720 | 14000 12070 | 16000 15760 | 14000 12070 | 16000 14760 | |
| 6 x 8 PCR | 13000 16080 | 15000 21420 | 13000 16080 | 15000 21420 | ||
| 8 x 8 PCR | 14000 13390 | 16000 17480 | 14000 13390 | 16000 17480 | ||
| 12 x 8 PCR | 13000 17220 | 15000 22930 | 13000 17220 | 15000 22930 | ||
| 24 Hematocrit Rotor | 12000 15805 | 12000 15800 | 12000 15800 | 12000 15800 | 12000 15800 | |
| 16 x 10/15ml | 13000 19490 | |||||
| 12 x 15ml | 11000 14330 | |||||
| 24 x 15ml | 5000 3500 | 5000 3500 | 5000 3500 | 5000 3500 | ||
| 30 x 15ml | 5000 3830 | 5000 3830 | 5000 3830 | 5000 3830 | ||
| 6 x 30 ml | 12000 14000 | 14000 19060 | 12000 14000 | 14000 19060 | ||
| 6 x 50ml(Sharp) | 12000 16050 | 12000 16050 | 12000 16050 | |||
| 6 x 50ml(Conical) | 12000 16050 | 13000 18840 | 12000 16050 | 13000 18840 | ||
| 6 x 50ml(Round) | 12000 15960 | 13000 18730 | 12000 15960 | 13000 18730 | ||
| 12 x 50ml | 5000 3860 | 5000 3860 | 5000 3860 | |||
| 24 x 50ml | 4000 2970 | |||||
| 4 x 85ml | 11000 13560 | 13000 18940 | 11000 13560 | 13000 18940 | ||
| 4 x 100ml | 10000 10310 | 12000 14850 | 10000 10310 | 12000 14850 | ||
| 6 x 100ml | 8000 7280 | 8000 7280 | 8000 7280 | 8000 7280 | ||
| 12 x 100ml | 4000 2970 | |||||
| 6 x 100ml | 10000 11380 | 9000 9210 | 10000 11380 | |||
| Swing Rotor | 4 x 5ml | 15000 19920 | 15000 19920 | 15000 19920 | 15000 19920 | |
| 4 x 4 x 5ml(Vacuum) | 4000 2380 | |||||
| 4 x 6 x 5ml(Vacuum) | 4000 2380 | |||||
| 4 x 4 x 7/10ml (Vacuum) | 4000 2770 | |||||
| 4 x 4 x 5/7/10ml | 4000 2580 | 4000 2770 | 4000 2770 | |||
| 4 x 6 x 5/7/10ml(adaptors) | 4000 2380 | 4000 2380 | 4000 2380 | |||
| 4 x 6 x 7/10ml(Vacuum) | 4000 2580 | 4000 2580 | 4000 2770 | 4000 2770 | ||
| 4 x 8 x 5/7/10ml (adaptors) | 4000 2380 | 4000 2380 | 4000 2380 | |||
| 4 x 8 x 5/7/10ml (Vacuum) | 4000 2770 | 4000 2770 | 4000 2380 | |||
| 4 x 12 x 5ml | 4000 2750 | |||||
| 4 x 16 x 5ml(Vacuum) | 4000 2520 | 4000 2520 | 4000 2520 | |||
| 4 x 22 x 5ml | 4000 2840 | |||||
| 4 x 12 x 7ml | 4000 3150 | |||||
| 4 x 16 x 7ml (Vacuum) | 4000 2880 | |||||
| 4 x 22 x 7ml | 4000 3410 | |||||
| 4 x 8 x 7/10ml (Vacuum) | 4000 2770 | |||||
| 4 x 16 x 10ml | 4000 3150 | |||||
| 4 x 18 x 10/15ml | 4000 3140 | |||||
| 4 x 4 x 15ml | 4000 2820 | 4000 2820 | 4000 3200 | 4000 3200 | ||
| 4 x 6 x 15ml | 4000 3200 | 4000 3200 | 4000 3200 | |||
| 4 x 8 x 15ml | 4000 3200 | 4000 3200 | 4000 3200 | |||
| 4 x 1 x 50ml | 5000 4420 | 5000 4420 | 5000 4730 | 5000 4730 | ||
| 4 x 2 x 50ml | 4000 2820 | 4000 2820 | 4000 3200 | 4000 3200 | ||
| 4 x 1 x 100ml | 5000 4420 | 5000 4420 | 5000 4730 | 5000 4730 | ||
| 4 x 2 x 100ml | 4000 3020 | 4000 3020 | 4000 3020 | |||
| 4 x 180ml (Round) | 4000 2580 | 4000 2580 | 4000 2580 | 4000 2580 | ||
| 4 x 300ml (Square) | 4000 3150 | 4000 3150 | 4000 3150 | |||
| 4 x 300ml (Round) | 4000 3180 | 4000 3180 | 4000 3180 | |||
| Well Plate Rotor | 2 x 3 x 48 Well | 4000 2300 | ||||
| 2 x 4 x 96 Well(Frame Type) | 4000 2910 | |||||
| 2 x 3 x 96 Well(Frame Type) | 4000 2020 | 4000 2020 | 4000 2020 | 4000 2020 | ||
| 2 x 4 x 96 Well(Box Type) | 4000 2770 | |||||
| 2 x 3 x 96 Well(Box Type) | 4000 1980 | 4000 1980 | 4000 1980 | 4000 1980 | ||
| Vertical Rotor | 16 x 5ml | 16000 16450 | 16000 16450 | 16000 16450 | 16000 19920 | |
| 8 x 30ml | 14000 19750 | 14000 19750 | 14000 19750 | 14000 19750 | ||
| 4x5ml | 15000 19920 |
