Features :
Widely used in blood bank, laboratory and hospital.
Brushless frequency motor which in great torque, free maintenance no powder pollution, quick in speed up and down.
The flexible axle driven system which drive and rotor directly, smooth in operation, low noise and small vibration.
Import compressors fluorine free double cycle cooling, cold and hot alternating easily, free evironment pollution and precise in temperature control.
There are 10 kinds of program and 10 kinds of acceleration and deceleration for your choice.
Micro computer control, LCD touch screen allows you to easily process all the parameters you need.
Automatically electric lid lock, super speed and imbalance protection.
The centrifuge body is made of high-quality steel, safe and reliable.
The features inside of the menu at the display can provide you;
Set the "Sleep Time" for the device,
Set the "Buzzer" coming at the end of process,
Set the "Timer" according to temperature or RPM for operating time of the device,
Set the "Defrost" for the solve or keep icing,
Set the "Lid Mode" for the end of process, you can set the cover manually or automatically.
Technical Specifications;
|
MODEL |
BRC-5180 |
BRC-5300 |
BRC-5800 |
| Maximum Speed (RPM) | 5000 | ||
| Maximum RCF (xg) | 4420 | 4730 | |
| Maximum Capacity | 4x180ml | 4x300ml | 4x800ml |
| Temperature Range | -20°C - 40°C | ||
| Temperature Accuracy | ±1°C | ||
| Speed Accuracy | ±50 rpm/min | ±20 rpm/min | |
| Timer Range | 99min59s | ||
| Noise | ≤60dB (A) | ≤65dB (A) | |
| Power Supply | AC220V 50Hz 10A | AC220V 50Hz 15A | |
| Dimension (mm) | 595x580x340 | 670x655x370 | 715x688x430 |
| Net Weight (kg) | 72 | 118 | 125 |
Rotor Types;
| MODEL ROTOR TYPE |
BRC-5180 | BRC-5300 | BRC-5800 | |
| CAPACITY | RPM RCF(xg) | RPM RCF(xg) | RPM RCF(xg) | |
| ANGLE ROTOR | 40 x 0.2ml | |||
| 24 x 0.5ml | ||||
| 30 x 0.5ml | ||||
| 40 x 0.5ml | ||||
| 12 x 1.5/2.0ml | ||||
| 20 x 1.5/2.0ml | ||||
| 24 x 1.5/2.0ml | ||||
| 10 x 5ml | ||||
| 6 x 10/15ml | ||||
| 4 x 8 PCR | ||||
| 24 Hematocrit Rotor | ||||
| 16 x 10/15ml | 4000 2820 | 4000 2820 | 4000 2820 | |
| 24 x 10/15ml | 4000 2820 | 4000 2820 | 4000 2820 | |
| 6 x 15ml | 5000 2540 | 5000 2540 | 5000 2540 | |
| 12 x 15ml | 5000 3080 | 5000 3080 | 5000 3080 | |
| 24 x 15ml | 5000 3500 | 5000 3500 | 5000 3500 | |
| 30 x 15ml | 5000 3830 | |||
| 4 x 50ml | 5000 2520 | 5000 2520 | 5000 2520 | |
| 6 x 50ml | 5000 2850 | 5000 2850 | 5000 2850 | |
| 12 x 50ml | 5000 3860 | 5000 3860 | ||
| 24 x 50ml | 5000 2970 | |||
| 4 x 100ml | 5000 2630 | 5000 2630 | 5000 2630 | |
| 6 x 100ml | 5000 3130 | 5000 3130 | 5000 3130 | |
| 12 x 100ml | 4000 2970 | 4000 2970 | ||
| SWING ROTOR | 4 x 4 x 5ml | 4000 2790 | ||
| 4 x 6 x 7ml | 4000 2790 | |||
| 4 x 8 x 10ml | 4000 2790 | |||
| 4 x 12 x 5ml | 4000 2480 | |||
| 4 x 22 x 5ml | 4000 2840 | |||
| 4 x 24 x 5ml | 4000 2840 | 4000 2840 | ||
| 4 x 12 x 7ml | 4000 2760 | |||
| 4 x 22 x 7ml | 4000 3140 | |||
| 4 x 24 x 7ml | 4000 3140 | 4000 3140 | ||
| 4 x 12 x 10/15ml | 4000 3140 | 4000 3140 | ||
| 4 x 18 x 10/15ml | 4000 3140 | |||
| 4 x 4 x 15ml | 4000 3200 | |||
| 4 x 6 x 15ml | 4000 3200 | |||
| 4 x 8 x 15ml | 4000 3200 | |||
| 4 x 1 x 50ml | 5000 4420 | 5000 4420 | 5000 4730 | |
| 4 x 2 x 50ml | 4000 3200 | |||
| 4 x 1 x 100ml | 5000 4730 | |||
| 4 x 2 x 100ml | 4000 3020 | |||
| 4 x 1 x 180ml | 4000 2580 | 4000 2580 | 4000 2580 | |
| 4 x 1 x 300ml (Square ) | 4000 2920 | 4000 2920 | ||
| 4 x 1 x 300ml (Round ) | 4000 2920 | 4000 2920 | ||
| 4 x 1 x 500ml (Square ) | 4000 3310 | |||
| 4 x 1 x 500ml (Round ) | 4000 3380 | |||
| 4 x 1 x 800ml (Round ) | 4000 3450 | |||
| 4 x 1 x 31 (Khan Tube) | 4000 2840 | 4000 2840 | ||
| MICROPLATE ROTOR | 2 x 2 x 96 Well | 4000 2020 | 4000 2020 | 4000 2020 |
| 2 x 4 x 96 Well | 4000 2490 | 4000 2490 | ||
| 2 x 3 x 48 Well | 4000 2300 | 4000 2300 | ||
| 4 x 4 x 96 Well | 4000 2840 |
