BRC-5800T Ultra High Capacity and High SPEED Refrigerated Universal Centrifuge

Name: BRC-5800T Ultra High Capacity and High SPEED Refrigerated Universal Centrifuge
Brand: INOVIALAB
SKU: BRC-5800T

INOVIALAB BRC-5800T is a high capacity and high speed refrigerated universal benchtop centrifuge designed for versatile laboratory applications with a wide range of rotor and adapter configurations.

With a maximum speed of 16000 rpm, maximum RCF of 29530 ×g and maximum capacity of 4 × 800 ml, the BRC-5800T provides a total nominal rotor capacity of 3.2 L for flexible laboratory workflows.

Its pre-cooling design, precise temperature control and operating temperature range of -20 °C to +40 °C allow samples to be processed under controlled conditions.

The touch LCD control panel, storage capacity for up to 100 programs, 10 acceleration/deceleration profiles and RPM/RCF conversion function provide precise and repeatable operation.

A brushless frequency-controlled motor, imbalance protection and overspeed sensors support reliable operation with low vibration, low noise and long-term laboratory use.

The BRC-5800T is suitable for blood banks, biochemistry, molecular biology, clinical laboratories, research laboratories and a wide range of sample preparation applications.

Features Order Form Documents Product Video

BRC-5800T Technical Specifications

Model	BRC-5800T
Maximum Speed	16000 rpm
Maximum RCF	29530 ×g
Maximum Capacity	4 × 800 ml
Total Nominal Rotor Capacity	3.2 L
Time Range	0~99h 59min 59sec
RPM/RCF Conversion	Yes
Noise Level	≤60 dB
Temperature Range	-20 °C ~ +40 °C
Acceleration/Deceleration	10 profiles
Speed Accuracy	±20 rpm
Temperature Accuracy	±1 °C
Program Memory	100 programs
Control Panel	Touch LCD
Motor	Brushless frequency-controlled motor
Voltage	AC 220V/110V, 50Hz/60Hz
Certificates	CE, ISO & calibration report available
Dimensions	720 × 715 × 420 mm
Net Weight	125 kg

Rotor and Capacity Options

Rotor	Rotor Type	Capacity / Configuration	Max. Speed (rpm)	Max. RCF (×g)
BRC-5800T-ROT-01	Swing Rotor (Round Cup)	4 × 800 ml	4000	3450
BRC-5800T-ROT-02	Microplate Rotor	4 × 4 / 1 × 96 Well	4000	2940
BRC-5800T-ROT-03	Swing Rotor	4 × 7 × 50 ml	4000	3460
BRC-5800T-ROT-04	Swing Rotor	4 × 50 ml / 100 ml	5000	4730
BRC-5800T-ROT-05	Swing Rotor	4 × 30 × 7 ml vacuum tube	4000	3130
BRC-5800T-ROT-06	Swing Rotor	4 × 30 × 5 ml vacuum tube 4 × 18 × 10 ml vacuum tube Fat bottle	4000	2840 / 3130 / 3830
BRC-5800T-ROT-07	Fixed Angle Rotor	4 × 8 PCR	16000	15760
BRC-5800T-ROT-08	Fixed Angle Rotor	6 × 8 PCR	16000	24370
BRC-5800T-ROT-09	Fixed Angle Rotor	8 × 8 PCR	16000	17480
BRC-5800T-ROT-10	Fixed Angle Rotor	12 × 8 PCR	16000	26090
BRC-5800T-ROT-11	Fixed Angle Rotor	40 × 0.5 ml	15000	22920
BRC-5800T-ROT-12	Fixed Angle Rotor	12 × 1.5 ml	16000	17940
BRC-5800T-ROT-13	Fixed Angle Rotor	24 × 1.5 ml	16000	23440
BRC-5800T-ROT-14	Fixed Angle Rotor	30 × 1.5 ml	16000	27170
BRC-5800T-ROT-15	Fixed Angle Rotor	48 × 1.5 ml	16000	27170
BRC-5800T-ROT-16	Fixed Angle Rotor	16 × 5 ml	16000	22020
BRC-5800T-ROT-17	Fixed Angle Rotor	6 × 10 ml	16000	21500
BRC-5800T-ROT-18	Fixed Angle Rotor	12 × 10 ml	16000	25800
BRC-5800T-ROT-19	Fixed Angle Rotor	16 × 10 ml	15000	26530
BRC-5800T-ROT-20	Fixed Angle Rotor	8 × 15 ml	15000	23680
BRC-5800T-ROT-21	Fixed Angle Rotor	12 × 15 ml	13000	20020
BRC-5800T-ROT-22	Fixed Angle Rotor	24 × 15 ml	5000	3500
BRC-5800T-ROT-23	Fixed Angle Rotor	30 × 15 ml	5000	3830
BRC-5800T-ROT-24	Fixed Angle Rotor	6 × 30 ml	16000	24890
BRC-5800T-ROT-25	Fixed Angle Rotor	12 × 30 ml	14000	20700
BRC-5800T-ROT-26	Fixed Angle Rotor	6 × 50 ml (conical)	15000	25080
BRC-5800T-ROT-27	Fixed Angle Rotor	8 × 50 ml (conical)	12000	18200
BRC-5800T-ROT-28	Fixed Angle Rotor	10 × 50 ml (conical)	10000	13870
BRC-5800T-ROT-29	Fixed Angle Rotor	24 × 50 ml	4000	2970
BRC-5800T-ROT-30	Fixed Angle Rotor	6 × 50 ml (round)	15000	24940
BRC-5800T-ROT-31	Fixed Angle Rotor	8 × 50 ml (round)	13000	20980
BRC-5800T-ROT-32	Fixed Angle Rotor	4 × 85 ml	14000	21960
BRC-5800T-ROT-33	Fixed Angle Rotor	6 × 85 ml	15000	22469
BRC-5800T-ROT-34	Fixed Angle Rotor	8 × 85 ml	10000	13780
BRC-5800T-ROT-35	Fixed Angle Rotor	4 × 100 ml	14000	20220
BRC-5800T-ROT-36	Fixed Angle Rotor	6 × 100 ml	13000	19230
BRC-5800T-ROT-37	Fixed Angle Rotor	8 × 100 ml	10000	13730
BRC-5800T-ROT-38	Fixed Angle Rotor	12 × 100 ml	4000	2970
BRC-5800T-ROT-39	Fixed Angle Rotor	4 × 250 ml	8000	9090
BRC-5800T-ROT-40	Fixed Angle Rotor	6 × 250 ml	7000	8050
BRC-5800T-ROT-41	Fixed Angle Rotor	4 × 300 ml	7000	8382
BRC-5800T-ROT-42	Fixed Angle Rotor	6 × 300 ml	6000	6600
BRC-5800T-ROT-43	Fixed Angle Rotor	24 capillaries	12000	15800
BRC-5800T-ROT-44	Swing Rotor	4 × 5 ml	15000	19920
BRC-5800T-ROT-45	Swing Rotor	4 × 30 ml	12000	20090
BRC-5800T-ROT-46	Swing Rotor	4 × 50 ml	10000	16240
BRC-5800T-ROT-47	Vertical Rotor	16 × 5 ml	16000	16450
BRC-5800T-ROT-48	Vertical Rotor	8 × 30 ml	14000	19750

Key Features

• Pre-cooling design

• 10 acceleration and deceleration profiles

• Wide range of rotor and adapter configurations

• Touch LCD control

• 100-program memory

• Brushless frequency-controlled motor

• Imbalance and overspeed sensors

• Low noise and low vibration

• Compact benchtop design
